SH2 Handheld Drone Detection Device
Category:
Key words:
SH2 Handheld Drone Detection Device
Specifications:
135mm × 60mm × 35mm
E-mail:
Product Category
Related Products
JF-1.5GHz Anti-Drone Jamming Module
Our UAV signal interference module is designed to be compact and easy to use. This device can be easily connected to the drone remote control or put in a backpack, which makes it a perfect solution for those on the road.
43dBm Digital Multi-subband Remote Control High Power Equipment Dual Band
Our UAV signal interference module is designed to be compact and easy to use. This device can be easily connected to the drone remote control or put in a backpack, which makes it a perfect solution for those on the road.
23dBm Digital Multi-subband Remote Control Medium Power Equipment Dual Band
Our UAV signal interference module is designed to be compact and easy to use. This device can be easily connected to the drone remote control or put in a backpack, which makes it a perfect solution for those on the road.
Description
- summary
The portable UAV detector adopts a low-power design and highly integrated design, and is capable of detecting mainstream rotary wing drones such as DJI and AUTEL that use OFDM high-definition image transmission, as well as various DIY crossings that use analog image transmission signals. The device adopts dual antennas and multi-channel simultaneous scanning, which has the characteristics of fast detection speed, high detection sensitivity, long detection distance, low false alarm rate, strong scalability, and easy use.
- Main functions and features
Passive Detection of Drones: Able to identify rotary wing drones such as DJI and AUTEL that use OFDM high-definition image transmission; Can detect various types of FPV using analog image transmission within 300MHz-6200MHz.
Sound and light alarm: headphone sound alarm, external sound and light alarm.
Log recording: It has alarm log recording and can export alarm logs through USB interface.
Headphone function: capable of obtaining alarm sound through headphones.
Firmware upgrade function: Upgrade firmware through USB interface.
Multi language switching: supports English and Russian.
Work status display: language, battery level
Working mode: default mode, user-defined scanning mode (currently not supported).
Custom detection: Users can modify, delete, or add detection drone feature libraries through the USB interface.
Spectrum function: Real time display of signal strength within the frequency range of 300-6200MHz.
- Technical indicators
Receiving frequency range: 300MHz-6200MHz
Identification type: OFDM high-definition image transmission signal, FPV (FM analog image transmission)
Detection distance: ≥ 1km
Detection sensitivity: better than -96dBm
Alarm detection methods: headphones, sound and light
Log recording: Supports no less than 500 alarm records
Upgrade and data export interface: mircoUSB
Power supply: Removable lithium battery (type-c charging)
Battery life: ≥ 4.5 hours (single battery)
Structural dimensions: ≤ 135mm × 60mm × 35mm (host without antenna)
Working weight: ≤ 500g (including single battery)
